Motors
Brush rotation: independent oil bath motor gear box
Suction: 3 stages with stainless steel fans and shaft
Plastics
Tanks: great thickness high density polyethylene
Squeegee blades: made in Latex usable on 4 sides
Hoses: suction and discharge made in high resistance polyurethane
Wheels: oil resistant
Mechanics
Chassis: double treatment with galvanizing + die-casting
Bearings: shielded against humidity and water seepages
Bolts and nuts: made in stainless steel where there are water contacts
Electric system
Carbon brushes: easily changeable
Boards: equipped with protective film against water and humidity
Solenoid valve: with Viton membrane resistant against chemical agents
Display: battery level
Made in Italy.
Technical Specifications
- CODE: LPTB01313
- MODEL: CT 110 BT 85
- SCRUBBING WIDTH (mm): 850
- SQUEEGEE WIDTH (mm): 1010
- PRODUCTIVITY (MAX SPEED) (m²/h): 5525
- BRUSH NO.: 2 (DISC)
- SOLUTION TANK (l): 110
- RECOVERY (l): 115
- POWER SUPPLY: 24V (4×6V) – 220Ah (C5)
- MAX SPEED (Km/h): 6.5
- WEIGHT (Kg): 231
- DIMENSIONS (L×W×H) (cm): 1504 × 909 × 1201
