Motors
Brush rotation: Independent oil bath motor gear box
Suction: 2 stages with stainless steel fans and shaft
Traction: Parallel axis differential with stainless steel bearings (BT version)
Plastics
Tanks: Great thickness high density polyethylene
Squeegee blades: Made in Latex usable on 4 sides
Hoses: Suction and discharge made in high resistance polyurethane
Wheels: Oil resistant
Mechanics
Chassis: Double treatment with galvanizing + die-casting
Bearings: Shielded against humidity and water seepages
Bolts and nuts: Made in stainless steel where there are water contacts
Electric System
Carbon brushes: Easily changeable
Boards: Equipped with protective film against water and humidity
Solenoid valve: With Viton membrane resistant against chemical agents
Sensors: Solution and recovery water level protected against accidental impacts
Display: Digital with hour counter and battery level
Made in Italy.
Technical Specifications
- Code: LPTE01414
- Model: CT70 B 55
- Scrubbing width: 550 mm
- Squeegee width: 815 mm
- Productivity (max speed): 1925 m²/h
- Brush no: 1 (Disc)
- Solution tank: 70 L
- Recovery tank: 75 L
- Power supply: 24V (2x12V) – 118Ah (C5)
- Max speed: 3.5 km/h
- Weight: 85 kg
- Dimensions (L×W×H): 1230 × 587 × 960 cm
